PTO Shaft OuterLock
This Heavy Duty PTO Shaft Outer Lock is designed to efficiently transfer power from tractor to rotavator with enhanced safety and durability.
The shaft consists of a pair of triangular tubes (inner & outer) available in customized lengths, mainly 14” and 16”, as per customer requirements. Each tube is fitted with precision-engineered triangular yokes, securely fastened using dowel pins.
These yokes are assembled with high-strength alloy steel UJ Cross, along with pin yoke and sharing yoke, ensuring smooth power transmission and long operational life.
The entire assembly is protected with a high-quality plastic guard, providing safety during operation, and is packed in a durable corrugated box for secure handling and transportation.
Product Specification
| OUTERLOCK PTO SPECIFICATION | |
|---|---|
| Triangular Tube Length | 14"/16" Customised |
| Yokes Material | EN8D |
| RAJ U.J. Cross | 38 MM (Alloy Steel) |
| Sharebolt | 10/12 MM Bolt |
| Colour | Black Powder Coated |
| Speed | 540 RPM |
| Usage/Application | Rotavators |
| Plastic Cover | First Quality |
